£79.82
To get an instant price for your order, please select your currency and follow steps 1 to 3.
Available with lead time | Contact Us
QSIL 216 is a transparent and colorless silicone formulation and is ideal for optical applications. The viscosity profile enables excellent flow around components and is excellent for potting complex parts. The chemical composition results in a cured product that is hydrolytically stable as well as reversion resistant. The silicone elastomer provides electrical insulation and physical shock resistance of components and enables environmental
protection.
Uncured Product
Property | Test Method | Value |
---|---|---|
Cure Profile | - | 30 mins at 150°C |
Cure Type | - | Addition |
Gel Time at 25°C/77°F | - | 6 hr |
Mix Ratio By Weight | - | 10:1 |
Rheology | - | Liquid, Newtonian |
Specific Gravity A | - | 1.02 |
Specific Gravity B | - | 1.01 |
Viscosity A | Brookfield | 4,000 cP |
Viscosity B | Brookfield | 700 cP |
Viscosity Mixed | Brookfield | 3,700 cP |
Cured Product
Property | Test Method | Value |
---|---|---|
Color | - | Transparent and Colorless |
Elongation at Break | ISO 37 | 100% |
Hardness Shore A | ASTM D 2240-95 | 40 |
Linear Coefficient of Thermal Expansion (ppm/°C) | - | 317 ppm/°C |
Linear Shrinkage (%) | - | <0.1 % |
Max Working Temp | - | 204 °C / 399 °F |
Min Working Temp | - | -55 °C / -67 °F |
Refractive Index at 589 nm | - | 1.405 |
Specific Heat (cal/g-°C) | - | 0.3 |
Tensile Strength | ISO 37 | 5.17 N/mm2 / 750 psi |
Thermal Conductivity | - | 0.18 W/mK |
Transmittance at 400 nm, 1 mm path (%) | - | 90.3 % |
Electrical Properties
Property | Test Method | Value |
---|---|---|
Dielectric Constant | ASTM D150 | 2.69 |
Dielectric Strength (V/mil) | - | >500 V/mil |
Dissipation Factor | ASTM D150 | 0.0006 |
Volume Resistivity (Ohms cm) | ASTM D257 | 1.7 E+15 ohms cm |
Storage
Property | Test Method | Value |
---|---|---|
Max Storage Temperature | - | 38 °C / 100 °F |
Shelf Life | - | 24 months |
