E-6010 – 0.175mm | Bright View Technologies
Elliptical LED Asymmetric Diffusers
£0.00
To get an instant quote for your custom parts, please select your currency and follow steps 1 to 4.
- Hides LEDS at distance of 1:1
- Diffuser Strength 60×10
- Efficiency in typical LED luminaire 91-95%
1 Sheets In Stock
Description
E-Series elliptical diffusers spread asymmetrically – more strongly in one direction than the other. They are used to diffuse a line of LEDs into a smooth line or to blend adjacent fluorescent lamps. They are also used to provide optimum spreading in wall-wash, linear, and cove applications. Because diffusion is only applied along one direction, efficiency can be even higher than C-Series diffusers. Bright View’s unique design causes less scalloping than other approaches, giving a smoother visual result.
Benefits
- Efficiency can be even higher than C-Series diffusers.
- Unique design causes less scalloping than other approaches, giving a smoother visual result.
Features
- Hides LEDS at distance of 1:1
- Diffuser Strength 60x10
- Efficiency in typical LED luminaire 91-95%
Recommended Uses
- Used to diffuse a line of LEDs into a smooth line or to blend adjacent fluorescent lamps. They are also used to provide optimum beam smoothing and spreading in wall-wash, linear, and cove applications.
Specifications
| Product | Hides LEDs at distance of | Diffuser Strength (higher numbers are more diffusive) | Efficiency in typical LED luminaire1 |
|---|---|---|---|
| E-6010 | 1 : 1 | 60 x 10 | 91 – 95 % |
| E-1560 | 1 : 1 | 15 x 60 | 90 – 95 % |
| E-3060 | 1 : 1 | 30 x 60 | 89 – 93 % |
| E-0160 | 1 : 1 | 0.3 x 60 | 90 – 96 % |
| E-0140 | 1 : 2 | 0.3 x 40 | 91 – 96 % |
